Join Our Innovative Team at

Silicon Brite Technologies

At Silicon Brite Technologies, we pioneer microchip technology and semiconductor solutions. Grow your career by working on impactful projects in power management systems and robotics.

Tech Vector

SBT3000

Industry's First Autonomous Power Line Smart AC Switch Controller Solutions

Automatic Smart AC Switch

Cost Effective & High Value Solution

90% Space Savings (vs. discrete solution)

In-cycle Over Voltage Load Isolation Low Power

Small FootPrint

High Effiency

Chip

Semiconductor Solutions

Explore our innovative analog and mixed-signal ICs designed for optimal performance in electronic systems.

Desk with color samples, camera, keyboard, and coffee.

Unlock Advantages with Our Semiconductor Solutions

Experience advanced microchip technology, reliable power management ICs, and exceptional support with our integrated circuit solutions.

Semiconductor Innovation

Semiconductor Innovation

Strong foundation in Innovation (R&D, Engineering, Patents) resulting in state-of-the-art products, solutions and commanding market position and leadership.

Customer-focused Company

Customer-focused Company

World class Designs – Applications – Service, with global reach, capability and operations.

End-Product Quality

End-Product Quality

Simplified and elegant Integrated Smart Power Management, Control, and Monitoring IC solutions resulting in enhanced reliability, safety, and quality in broad end applications.

Man in suit using a glowing digital interface.

Semiconductor Innovation

Strong foundation in Innovation (R&D, Engineering, Patents) resulting in state-of-the-art products, solutions and commanding market position and leadership.

Business team meeting around a table.

Customer-focused Company

World class Designs – Applications – Service, with global reach, capability and operations.

Hand interacting with a tablet showing data.

End-Product Quality

Simplified and elegant Integrated Smart Power Management, Control, and Monitoring IC solutions resulting in enhanced reliability, safety, and quality in broad end applications.

Our Products

Explore our range of high-performance ICs, including smart AC/DC controllers and overvoltage protection devices, designed for superior performance.

View all products
product

SBT3000 Autonomous Power Line Smart AC Switch Controller

The SBT3000 is a patented, autonomous high voltage AC switch controller device, which monitors incoming line voltage to ensure that the downstream load only operates within its safe maximum continuous voltage ratings. In the event of over-voltage line conditions, the SBT3000 will automatically disable the AC switch to protect and isolate the load and minimize the potential of catastrophic failure modes. The SBT3000 Evaluation Module (EVB), is an engineering circuit board designed for testing the operation of the SBT3000 integrated circuit. The SBT3000 EVB contains an SO8 IC socket and all the necessary support components to be able to apply an input voltage and a moderate load in order to evaluate the overvoltage protection features of the device.

product

SBT3001 Instant Off, Power Line Smart AC Switch Controller

The SBT3001 is a patented, high voltage AC switch controller device which monitors incoming line voltage to ensure that the downstream load only operates within its safe maximum continuous voltage ratings. In the event of over-voltage line conditions, the SBT3001 will immediately disable the AC switch to protect and isolate the load and minimize the potential of catastrophic failure modes. Once the line voltage has stabilized back within a safe operating range for the duration of the recovery timer interval (user adjustable via external timing capacitor), normal load operation will resume in the following cycle and be synchronized to zero Line to Load voltage condition, thereby resulting in minimal in-rush current stress.

product

SBT3002 High voltage DC Over Voltage Protector.

The SBT3002 is a patented, high voltage DC over voltage protector. After an AC power source and bridge rectifier, the SBT3002 connects and monitors the Cbus (capacitor) DC voltage. If the capacitor voltage is too high, the SBT3002 disconnects the high voltage capacitor and Load, from the DC power source. The connection of the Cbus (capacitor) is synchronized with the zero crossing of the AC line, minimizing the turn-on inrush current. The operation of the SBT3002 prevents capacitors and loads from being damaged by line overvoltage, and minimizes turn-on inrush current.

product

SBT3200 Autonomous Power Line Smart OVP + OCP Controller

The SBT3200 is a patent pending, high voltage AC switch controller device which monitors an incoming AC power line voltage and load current, to ensure that the downstream load only operates within its safe maximum continuous voltage and current ratings. In the event of either an Over-voltage line condition, or an Over-current load condition, the SBT3200 will immediately disable the AC switch to protect and isolate the load. This minimizes the potential of catastrophic failure modes. The SBT3200 has the additional feature of latching off until manually reset, in the event of an overcurrent. Once the line voltage and load current has stabilized back within a safe operating range for the duration of the recovery timer interval (user adjustable via external timing capacitor), normal load operation will resume in the following AC power line cycle. Turn-on (or re-turn-on) of the AC source to the load is always synchronized to zero Line-to-Load voltage condition, thereby resulting in minimal in-rush current stress.

product

SBT3800 Multi Phase AC Power Monitor

The SBT3800 is a Smart Power Monitor IC that reads line voltage, current, frequency, as well as ambient temperature and provide outputs in the form of a synchronous serial data stream. The SBT3800 will accept a power input from DC to 100Hz so that solar and alternative energy sources can also be monitored. The SBT3800 has a current limited output, and can, optionally drive an inexpensive opto-coupler to provide electrical isolation between the line and the data side of the SBT3800. The output data is sent with a parity bit to enhance data transmission integrity. The SBT3800 consumes only a small amount of power and can be powered directly from the power line.

product

SBT3850 Industrial V-I Measurement

The SBT3850 is a versatile industrial V-I measurement IC that has built-in three-phase peak detection and interrupt functions. The peak detect detects the peak current and interrupts a microcontroller to indicate that current has exceeded a preset threshold. The interrupt output may be also used as a rapid method of turning off power drivers. The temperature sensor measures the temperature of the current sense resistors, in order to factor a temperature correction into the voltage read from the current shunt resistors.

product

SBT4000 lIoT Edge Inrush Current Controller

The SBT4000 is an automatic DC Current controller used to control the DC inrush current into a rectified DC capacitor or in AC to DC electronic fuse (E-Fuse) type applications. When power is first applied, the SBT4000 gradually ramps up the charge on the DC bus capacitor until the peak of the AC input voltage is reached. When this happens, the controller sets the Power Good indicator to high, after which, the load can then be turned on. If at any time the current sense circuit senses that the load current is too high, then it will set the Power Good indicator low, and re-start the turn-on sequence. In this configuration, the SBT4000 can also be used as an electronic fuse (E-Fuse).

product

SBT5000 Multi-channel Touch Switches

The SBT5000 is a simple touch or proximity switch for power control and sensing applications. When a user comes in very close proximity to the touchpads or touches them, the SBT5000 is enabled and can control a microcontroller and/or turn on an external optocoupler for reporting and control. This can also be used to control the system power through the connected Silicon Brite SBT3000 Overvoltage Protection IC Autonomous Power Line Smart AC Switch Controller. When the system has finished the required functions, it can turn off the system power by resetting the controller.

product

SBT6300 Smart Power Control and Monitor

The SBT6300 is a high-reliability three-channel, AC power controller and monitor. Synchronous serial data from a digital controller can turn on/off any of the three AC loads using external triacs, or relays. The current consumed by those loads can be read back through the same interface to confirm that the load is operating as expected. The line voltage can also be read via the SPl-like interface.

product

SBT6620 SPI Port Expander

The SBT6620 is an intelligent and reliable Synchronous Serial Interface (SPI-like) controlled, eight-channel peripheral load driver and input monitor IC. The status of each of the I/O pins can always be read and can optionally be configured as an output. When configured as an output, each I/O pin is internally current limited and can sink or source current. The output voltage and input voltage threshold on the I/O pins scales to the voltage input so that voltages other than the controller Vdd can be used and allows the IC to monitor higher voltages, like a high voltage AC, or DC rail. This feature contributes to system versatility and reliability.

product

SBT7000 Integrated Power Module

The SBT7000 is an easy to use, convenient power module with integrated IGBT power transistors, an electrically isolated IGBT driver, and multiple safety features. The internal stepper driver manages the repetitive high-speed task of controlling the on/off and dead time states of the individual IGBTs. Changes to the stepper parameters can be made even when the stepper is operating. This eliminates controller synchronization issues. The analog temperature output of the SBT7000 can be connected with other SBT7000 temperature outputs so that a single ADC can measure the peak temperature of all SBT7000 ICs in the system.

product

SBT8830 IGBT Driver

The SBT8830 is a single channel low and high side IGBT driver with over current, over-temperature, and under-voltage sensing features enabling a more reliable system. For three-phase BLDC or stepper motor drive applications, multiple SBT8830 parts may be used in which each part has differential output drivers for the fastest and most direct connection to IGBT emitters.
